WdToggle : Direct System Calls To Enable WDigest Credential Caching

WdToggle is a Proof of Concept Cobalt Strike Beacon Object File which uses direct system calls to enable WDigest credential caching and circumvent Credential Guard (if enabled).

What is this repository for?

  • Demonstrate the usage of direct systems calls using inline-assembly to provide a more opsec safe way of interacting with the LSASS process.
  • Enable WDigest credential caching by toggling the g_fParameter_UseLogonCredential global parameter to 1 within the LSASS process (wdigest.dll module).
  • Circumventing Credential Guard (if enabled) by toggling the g_IsCredGuardEnabled variable to 0 within the LSASS process (wdigest.dll module).
  • Execute this code within the Beacon process using a Beacon object file.

How do I set this up?

We will not supply compiled binaries. You will have to do this yourself:

  • Clone this repository.
  • Make sure you have the Mingw-w64 compiler installed. On Mac OSX for example, we can use the ports collection to install Mingw-w64 (sudo port install mingw-w64).
  • Run the make command to compile the Beacon object file.
  • Within a Cobaltstrike beacon context run the inline-execute command and provide the path to the object WdToggle.o file.
  • Run the Cobaltstrike logonpasswords command (Mimikatz) and notice that clear text passwords are enabled again for new user logins or users who unlock their desktop session.

Limitations

  • This memory patch is not reboot persistent, so after a reboot you must rerun the code.
  • The memory offset to the wdigest!g_fParameter_UseLogonCredential and wdigest!g_IsCredGuardEnabled global variable could change between Windows versions and revisions. We provided some offsets for different builds, but these can change in future releases. You can add your own version offsets which can be found using the Windows debugger tools.
C:\Program Files (x86)\Windows Kits\10\Debuggers\x64>cdb.exe -z C:\Windows\System32\wdigest.dll

0:000>x wdigest!g_fParameter_UseLogonCredential
00000001`800361b4 wdigest!g_fParameter_UseLogonCredential = <no type information>
0:000> x wdigest!g_IsCredGuardEnabled
00000001`80035c08 wdigest!g_IsCredGuardEnabled = <no type information>
0:000>

Detection

To detect credential theft through LSASS memory access, we could use a tool like Sysmon. Sysmon can be configured to log processes opening a handle to the lsass.exe process. With this configuration applied, we can gather telemetry for suspicious processes accessing the LSASS process and help detecting possible credential dumping activity. Of course, there are more options to detect credential theft, for example using an advanced detection platform like Windows Defender ATP. But if you don’t have the budget and luxury of using these platforms, then Sysmon is that free tool that can help to fill up the gap.
