SSF : Secure Socket Funneling Network Tool

Secure Socket Funneling (SSF) is a network tool and toolkit. It provides simple and efficient ways to forward data from multiple sockets (TCP or UDP) through a single secure TLS tunnel to a remote computer.

It is cross platform (Windows, Linux, OSX) and comes as standalone executables.

Features

  • Local and remote TCP port forwarding
  • Local and remote UDP port forwarding
  • Local and remote SOCKS server
  • Local and remote shell through sockets
  • File copy
  • Native relay protocol
  • TLS connection with the strongest cipher-suites

How to use?

Command line

Client

Usage: ssf[.exe] [options] server_address

Options:

  • -v verbose_level: Verbosity: critical|error|warning|info|debug|trace (default: info)
  • -q: Quiet mode. Do not print logs
  • -p port: Remote port (default: 8011)
  • -c config_file_path: Specify configuration file. If not set, ‘config.json’ is loaded from the current working directory
  • -m attempts: Max unsuccessful connection attempts before stopping (default: 1)
  • -t delay: Time to wait before attempting to reconnect in seconds (default: 60)
  • -n: Do not try to reconnect client if connection is interrupted
  • -g: Allow gateway ports. Allow client to bind local sockets for a service to a specific address rather than “localhost”
  • -S: Display microservices status (on/off)

Services options:

  • -D [[bind_address]:]port: Run a SOCKS proxy on the server accessible on [[bind_address]:]port on the local side
  • -F [[bind_address]:]port: Run a SOCKS proxy on the local host accessible from the server on [[bind_address]:]port
  • -X [[bind_address]:]port: Forward server shell I/O to the specified port on the local side. Each connection creates a new shell process
  • -Y [[bind_address]:]port: Forward local shell I/O to the specified port on the server
  • -L [[bind_address]:]port:host:hostport: Forward TCP connections to [[bind_address]:]port on the local host to host:hostport on the server
  • -R [[bind_address]:]port:host:hostport: Forward TCP connections to [[bind_address]:]port on the server to host:hostport on the local side
  • -U [[bind_address]:]port:host:hostport: Forward local UDP traffic on [[bind_address]:]port to host:hostport on the server
  • -V [[bind_address]:]port:host:hostport: Forward UDP traffic on [[bind_address]:]port on the server to host:hostport on the local side

Server

Usage: ssfd[.exe] [options]

Options:

  1. -v verbose_level: Verbosity: critical|error|warning|info|debug|trace (default: info)
  2. -q: Quiet mode. Do not print logs
  3. -c config_file_path: Specify configuration file. If not set, ‘config.json’ is loaded from the current working directory
  4. -p port: Local port (default: 8011)
  5. -R: The server will only relay connections
  6. -l host: Set server bind address
  7. -g: Allow gateway ports. Allow client to bind local sockets for a service to a specific address rather than “localhost”
  8. -S: Display microservices status (on/off)

  • Copy

The copy feature must be enabled on both client and server configuration file:

{
“ssf”: {
“services”: {
“copy”: { “enable”: true }
}
}
}

Usage: ssfcp[.exe] [options] [host@]/absolute/path/file [[host@]/absolute/path/file]

Options:

  • -v verbose_level: Verbosity: critical|error|warning|info|debug|trace (default: info)
  • -q: Quiet mode. Do not print logs
  • -c config_file_path: Specify configuration file. If not set, ‘config.json’ is loaded from the current working directory
  • -p port: Remote port (default: 8011)
  • -t: Use stdin as input
  • --resume: Attempt to resume file transfer if the destination file exists
  • --check-integrity: Check file integrity at the end of the transfer
  • -r: Copy files recursively
  • --max-transfers arg: Max transfers in parallel (default: 1)

Also Read – Dnssearch : A Subdomain Enumeration Tool

Examples

Client

The client will run a SOCKS proxy on port 9000 and transfer connection requests to the server 192.168.0.1:8000

ssf -D 9000 -c config.json -p 8000 192.168.0.1

  • Server

The server will be bound to port 8011 on all the network interfaces

ssfd

The server will be bound to 192.168.0.1:9000

ssfd -p 9000 -l 192.168.0.1

  • Copy local file to remote filesystem

ssfcp [-c config_file] [-p port] path/to/file host@absolute/path/directory_destination
ssfcp [-c config_file] [-p port] path/to/file* host@absolute/path/directory_destination
ssfcp [-c config_file] [-p port] -r path/to/dir host@absolute/path/directory_destination

  • Pipe file from standard input to remote filesystem

data_in_stdin | ssfcp [-c config_file] [-p port] -t host@path/to/destination/file_destination

  • Copy remote files to local filesystem :

ssfcp [-c config_file] [-p port] remote_host@path/to/file absolute/path/directory_destination

ssfcp [-c config_file] [-p port] remote_host@path/to/file* absolute/path/directory_destination

ssfcp [-c config_file] [-p port] -r remote_host@path/to/dir absolute/path/directory_destination

Configuration file

{
“ssf”: {
“arguments”: “”,
“circuit”: [],
“http_proxy”: {
“host”: “”,
“port”: “”,
“user_agent”: “”,
“credentials”: {
“username”: “”,
“password”: “”,
“domain”: “”,
“reuse_ntlm”: true,
“reuse_nego”: true
}
},
“socks_proxy”: {
“version”: 5,
“host”: “”,
“port”: “1080”
},
“tls” : {
“ca_cert_path”: “./certs/trusted/ca.crt”,
“cert_path”: “./certs/certificate.crt”,
“key_path”: “./certs/private.key”,
“key_password”: “”,
“dh_path”: “./certs/dh4096.pem”,
“cipher_alg”: “DHE-RSA-AES256-GCM-SHA384”
},
“services”: {
“datagram_forwarder”: { “enable”: true },
“datagram_listener”: {
“enable”: true,
“gateway_ports”: false
},
“stream_forwarder”: { “enable”: true },
“stream_listener”: {
“enable”: true,
“gateway_ports”: false
},
“copy”: { “enable”: false },
“shell”: {
“enable”: false,
“path”: “/bin/bash|C:\windows\system32\cmd.exe”,
“args”: “”
},
“socks”: { “enable”: true }
}
}
}

Arguments

Configuration keyDescription
argumentsuse configuration arguments instead of given CLI arguments (except -c)

The arguments key lets the user customize the command line arguments in the configuration file. This feature is a convenient way to save different client connection profiles.

Given the following configuration file conf.json:

{
“ssf”: {
“arguments”: “10.0.0.1 -p 443 -D 9000 -L 11000:localhost:12000 -v debug”
}
}

SSF will extract the given arguments and use them as a replacement of the initial arguments (except -c).

For example, ssf -c conf.json will be equivalent to ssf 10.0.0.1 -p 443 -D 9000 -L 11000:localhost:12000 -v debug:

  • connect to 10.0.0.1:443 (10.0.0.1 -p 443)
  • start the SOCKS service (-D 9000)
  • start the TCP port forwarding service (-L 11000:localhost:12000)
  • set verbosity level to debug (-v debug)

Circuit

Configuration keyDescription
circuitrelay chain servers used to establish the connection to the remote server

The circuit is a JSON array containing the bounce servers and ports which will be used to establish the connection. They are listed as follow:

{
“ssf”: {
“circuit”: [
{“host”: “SERVER1”, “port”:”PORT1″},
{“host”: “SERVER2”, “port”:”PORT2″},
{“host”: “SERVER3”, “port”:”PORT3″}
]
}
}

This configuration will create the following connection chain:

CLIENT -> SERVER1:PORT1 -> SERVER2:PORT2 -> SERVER3:PORT3 -> TARGET

Proxy

SSF supports connection through:

  • HTTP proxy by using the CONNECT HTTP method
  • SOCKS proxy (v4 or v5)

HTTP Proxy

Configuration keyDescription
http_proxy.hostHTTP proxy host
http_proxy.portHTTP proxy port
http_proxy.user_agentUser-Agent header value in HTTP CONNECT request
http_proxy.credentials.usernameproxy username credentials (all platform: Basic or Digest, Windows: NTLM and Negotiate if reuse = false)
http_proxy.credentials.passwordproxy password credentials (all platform: Basic or Digest, Windows: NTLM and Negotiate if reuse = false)
http_proxy.credentials.domainuser domain (NTLM and Negotiate auth on Windows only)
http_proxy.credentials.reuse_ntlmreuse current computer user credentials to authenticate with proxy NTLM auth (SSO)
http_proxy.credentials.reuse_kerbreuse current computer user credentials (Kerberos ticket) to authenticate with proxy Negotiate auth (SSO)

Supported authentication schemes:

  • Basic
  • Digest
  • NTLM (Windows only)
  • Negotiate with Kerberos (reuse computer user credentials)

SOCKS proxy

Configuration keyDescription
socks_proxy.versionSOCKS version (4 or 5)
socks_proxy.hostSOCKS proxy host
socks_proxy.portSOCKS proxy port

No authentication scheme supported.

TLS

Using external files
Configuration keyDescription
tls.ca_cert_pathrelative or absolute filepath to the CA certificate file
tls.cert_pathrelative or absolute filepath to the instance certificate file
tls.key_pathrelative or absolute filepath to the private key file
tls.key_passwordkey password
tls.dh_pathrelative or absolute filepath to the Diffie-Hellman file (server only)
tls.cipher_algcipher algorithm

With default options, the following files and folders should be in the working directory of the client or the server:

  • ./certs/dh4096.pem
  • ./certs/certificate.crt
  • ./certs/private.key
  • ./certs/trusted/ca.crt

Where:

  • dh4096.pem contains the Diffie-Hellman parameters (generate DH parameters)
  • certificate.crt and private.key are the certificate and the private key of the SSF server or client (generate certificate)
  • ca.crt is the concatenated list of certificates trusted by the SSF server or client (generate CA)

If you want those files at different paths, it is possible to customize them thanks to the TLS path keys:

{
“ssf”: {
“tls” : {
“ca_cert_path”: “./certs/trusted/ca.crt”,
“cert_path”: “./certs/certificate.crt”,
“key_path”: “./certs/private.key”,
“key_password”: “”,
“dh_path”: “./certs/dh4096.pem”,
“cipher_alg”: “DHE-RSA-AES256-GCM-SHA384”
}
}
}

Using configuration file only

Configuration keyDescription
tls.ca_cert_bufferCA certificate file content in PEM format (⚠️ \n between data and PEM header/footer)
tls.cert_bufferinstance certificate file content in PEM format (⚠️ \n between data and PEM header/footer)
tls.key_bufferprivate key file content in PEM format (⚠️ \n between data and PEM header/footer)
tls.key_passwordkey password
tls.dh_bufferDiffie-Hellman parameters file content in PEM format (⚠️ \n between data and PEM header/footer, server only)
tls.cipher_algcipher algorithm

You can integrate the TLS parameters directly into the configuration file by using the tls.ca_cert_buffer, tls.cert_buffer, tls.key_buffer and tls.dh_buffer keys.

{
“ssf”: {
“tls” : {
“ca_cert_buffer”:”—–BEGIN CERTIFICATE—–\n…\n—–END CERTIFICATE—–“,
“cert_buffer”:”—–BEGIN CERTIFICATE—–\n…\n—–END CERTIFICATE—–“,
“key_buffer”:”—–BEGIN RSA PRIVATE KEY—–\n…\n—–END RSA PRIVATE KEY—–“,
“key_password”: “”,
“dh_buffer”:”—–BEGIN DH PARAMETERS—–\n…\n—–END DH PARAMETERS—–“,
“cipher_alg”: “DHE-RSA-AES256-GCM-SHA384”
}
}
}

Certificates, private keys and DH parameters must be in PEM format. ⚠️ \n between data and PEM header/footer are mandatory.

Microservices

Configuration keyDescription
services.*.enableenable/disable microservice
services.*.gateway_portsenable/disable gateway ports
services.shell.pathbinary path used for shell creation
services.shell.argsbinary arguments used for shell creation

SSF’s features are built using microservices (TCP forwarding, remote SOCKS, …)

There are 7 microservices:

  • stream_forwarder
  • stream_listener
  • datagram_forwarder
  • datagram_listener
  • copy
  • socks
  • shell

Each feature is the combination of at least one client side microservice and one server side microservice.

This table sums up how each feature is assembled:

ssf featuremicroservice client sidemicroservice server side
-L: TCP forwardingstream_listenerstream_forwarder
-R: remote TCP forwardingstream_forwarderstream_listener
-U: UDP forwardingdatagram_listenerdatagram_forwarder
-V: remote UDP forwardingdatagram_forwarderdatagram_listener
-D: SOCKSstream_listenersocks
-F: remote SOCKSsocksstream_listener
-X: shellstream_listenershell
-Y: remote shellshellstream_listener

This architecture makes it easier to build remote features: they use the same microservices but on the opposite side.

ssf and ssfd come with pre-enabled microservices. Here is the default microservices configuration:

{
“ssf”: {
“services”: {
“datagram_forwarder”: { “enable”: true },
“datagram_listener”: { “enable”: true },
“stream_forwarder”: { “enable”: true },
“stream_listener”: { “enable”: true },
“socks”: { “enable”: true },
“copy”: { “enable”: false },
“shell”: { “enable”: false }
}
}
}

To enable or disable a microservice, set the enable key to true or false.

Trying to use a feature requiring a disabled microservice will result in an error message.

How to generate certificates for TLS connections

Manually

  • Generating Diffie-Hellman parameters

openssl dhparam 4096 -outform PEM -out dh4096.pem

  • Generating a self-signed Certification Authority (CA)

First of all, create a file named extfile.txt containing the following lines:

[ v3_req_p ]
basicConstraints = CA:FALSE
keyUsage = nonRepudiation, digitalSignature, keyEncipherment

Then, generate a self-signed certificate (the CA) ca.crt and its private key ca.key:

openssl req -x509 -nodes -newkey rsa:4096 -keyout ca.key -out ca.crt -days 3650

  • Generating a private key and a certificate (signed with the CA)

Generate a private key private.key and a certificate signing request certificate.csr:

openssl req -newkey rsa:4096 -nodes -keyout private.key -out certificate.csr

Generate the certificate (certificate.pem) by signing the CSR with the CA (ca.crt, ca.key):

openssl x509 -extfile extfile.txt -extensions v3_req_p -req -sha1 -days 3650 -CA ca.crt -CAkey ca.key -CAcreateserial -in certif
